AVMD-128-192M


Variable Message Display


  • Big size and modular design
  • Supports any language
  • Real time information from server

The AVMD-128-192M is LED Variable Message Display to use in variable public information systems like air quality displays, government notice displays, parking displays etc.
AVMD-128-192M can display 7 colour of text and graphics. It support display of all languages.
The AVMD-128-192M is working in real time with server.


LTEGPRSethernetUSBbhrightness-settingconfig-wwwhigh-brightnessSD-cardLCDRGBtamper-alertremote-configremote-updatewide-viewsmart-citymultilangualreal-time-datacloud-ready

Applications

  • Bus, tram, trolleybus, railway and metro stations
  • Parkings, weight bridges, toll plaza information etc.


Size of displaying area1280 x 1920mm (W x H)
Size of body of display1280 x 1920 x 100 mm (W x H x D)
Pitch of pixels10mm
Display resolution128 (H) x 192( V)
Displays coloursRGB 7 colours, day light readable (optional amber)
LED typeSMD PLCC-2
Angle of viewing120°V, 120°H
Intensity of Light6000 cdm or more
Line of text16 line English/ 12 line Hindi any other Indian language
Line height16 pixels (Hindi)
GraphicsPictorial and single colour graphics support (any one from 7 colours)
Communication to serverGPRS or LAN
Controller and antennaInbuilt in display
MaintenanceFront maintenance
Extra featuresInbuilt separate clock
Power supply90 ‒ 240V AC (inbuilt supply)
Powers consumption
Screen protectionLED modules are self protected
Body materialPowder coated aluminium
Weight
Environmental specificationsOperating temperature: 0 to +70°C, humidity: 5% to 95% RH, sealing IP65

Communication protocolTCP/IP
Communication intervalReal time (configurable interval from 1s to 256s)
ConfigurationSMS or LAN (inbuilt web-server), 16x2 LCD for diagnosis
Brightness controlAuto-brightness according ambient light or manual from server
Display region controlMultiple regions, multiple messages, refresh whole display, refres only one region
Language supportAll indian languages, right to left langauges, any European languages support
Text effectsScrooling left, right, up, down; blinking, stable text

Variable message displays are build to order. We provide modifications to the basic specification depending on individual requirements and local regulations. We also offer customised mounting brackets. For enquiry - Contact us


  • Online documentation
    The documentation page provides detailed product specifications and complete instructions for use. Please read it before using the product.
